Focus Peaking Explained: What the Coloured Edges Really Tell You

What peaking is, in plain words

Focus peaking is an overlay on your monitor or viewfinder. The camera looks for edges where neighbouring pixels change sharply from light to dark, and it paints those edges in a colour you choose, usually red, yellow or cyan. The idea is simple: where you see colour, there is fine detail, and fine detail usually means the lens is focused there.

The word that matters is usually. Peaking does not measure focus directly. It measures local contrast in the image the camera is showing you, and sharp focus is only one of several things that produce contrast. A coarse fabric, a hairline or a patterned wall can light up with colour even when they sit slightly in front of or behind the true focal plane.

In the first module we ask learners to treat peaking as a hint, not a verdict. It tells you where to look more closely. It is quick, it works while the camera is moving, and it saves you from staring at a small screen guessing, but it rarely settles the question alone.

Why the colour sometimes lies

Peaking has a sensitivity setting, and the default is often generous. At a high setting, even a slightly soft edge crosses the threshold and gets coloured, so the whole face looks sharp when the eyes are a hair off. Lowering the sensitivity makes the overlay stricter and shows you less colour, which is exactly what you want when precision matters.

Scene content also fools it. A bright, high-contrast background such as a window, a striped shirt or foliage can draw more colour than your subject, pulling your eye away from the point that counts. Skin is the opposite: smooth, low-contrast surfaces give peaking very little to grab, so a perfectly focused cheek may show almost nothing.

Noise is a third trap. In dim event halls, high ISO grain creates tiny edges everywhere, and some cameras paint them. If the overlay flickers across a flat grey wall, you are looking at noise, not focus. Check your gain and your sensitivity before you trust a single coloured pixel.

• Lower sensitivity when everything seems to be in focus
• Pick an overlay colour that contrasts with the subject
• Expect weak response on smooth skin
• Watch for flicker on flat walls in dim rooms

Magnification: the check that settles it

Magnification, sometimes called focus assist or punch-in, enlarges a small part of the frame so you can judge sharpness with your own eyes. At five or ten times, a soft eyelash is obvious in a way no overlay can show. It is the closest thing a camera monitor offers to inspecting the file afterwards.

The habit we teach is a two-step. First use peaking to find roughly where the focal plane sits, then punch in on the one detail that matters, such as the near eye in a portrait or the edge of a name card on a table, and fine-tune there. Then punch out and confirm the framing has not shifted.

Magnification has a cost: most cameras cannot record while zoomed in, and some freeze or crop the live feed. That makes it a pre-shoot and between-takes tool. During a take you lean on peaking and on your discipline, which is why the pre-shoot check has to be thorough.

Test targets and the front-focus problem

Some lenses and camera bodies consistently focus a little in front of or behind the point you chose. You cannot see this with peaking, because the overlay faithfully shows the wrong plane as sharp. A simple test target settles it: a flat chart with fine lines at an angle, shot at the widest aperture, with a ruler or scale running away from the camera.

Shoot the target at the apertures and distances you actually use, then review the frames magnified. If the sharpest line sits consistently ahead of your focus point, you know the offset and can correct it in the camera menu where the model allows, or simply compensate by habit.

Do this once per lens and body pairing, and write the result down. In a multi-camera setup, the same lens model on two bodies can behave differently, and finding that out in a test session costs ten minutes. Finding it out during a live ceremony costs frames you cannot reshoot.

• Use a flat chart with fine, angled lines
• Test at your working aperture and distance
• Record the offset for each lens and body
• Repeat when a lens or body changes

Keeping focus honest during a shoot

Autumn events tend to mean dim venues, moving guests and long evenings, and focus drifts more than people expect. Lenses breathe, subjects lean in, and a tired operator relaxes without noticing. Build short checks into the rhythm of the day rather than relying on a single confirmation at the start.

A practical routine is to confirm focus after every lens change, after any bump to the tripod, at each scene change and whenever the light level drops noticeably. On a second camera, ask the operator to say aloud that focus is checked, so the habit is shared and no one assumes the other person did it.

Monitoring matters here too. A small camera screen in daylight is a poor judge, so shade it, raise its brightness and, where the budget allows, use an external monitor. None of this is complicated, but it only works when everybody on the team does it the same way every time.

A short routine to take away

Put the pieces in order and the process is brief. Set peaking to a strict sensitivity and a colour that stands out from the scene. Frame your subject and let the overlay show you roughly where focus sits. Punch in on the single most important detail and adjust until it is crisp.

Next, punch out and check the frame, then shoot a short test clip and review it magnified, ideally on a larger screen than the camera's own. If you work with more than one camera, repeat this on each and compare the results side by side before the guests arrive.

Finally, note the settings and any lens offsets in your handover notes, so the next person starts from what you already know rather than rediscovering it under pressure.

• Strict peaking, contrasting colour
• Peaking to find the plane, magnification to confirm
• Review a test clip on a larger screen
• Write offsets into the handover notes
